Place of Origin:
Guangdong, China
Brand Name:
HILINK
Certification:
CE FCC Rohs
Model Number:
HL-X2-10g-LR
10GBase-LR Transceiver 1310nm X2 Transceiver Module10KM X2 Module X2-10GB-LR
Feature
Compatible with X2 MSA Rev2.0b
Support of IEEE 802.3ae 10GBASE-LR at 10.3125Gbps
Transmission Distance up to 10Km(SMF)
SC Receptacle 1310nm DFB Laser
SC Duplex Optical Connector
Hot Pluggable 70-PIN Connector with XAUI Electrical Interface
Management and control via MDIO 2-wire interface
Power Supply :+3.3V, APS(+1.2V)
Diagnostic Optics Monitoring
Temperature Range: 0~ 70 °C
ROHS Compatible
Applications
10GE Ethernet switches and routers
10GE Core-routers
10GE Storage
Other 10Gbps Ethernet Transmission System
Specification
| Standards | IEEE Std. 802.3ae |
| Switch | S1: Enables/disables Link Pass Through |
| Status LEDs | PWR (Power): ON = connection to external AC power |
| Link: ON = unit is receiving link pulses from a compliant device | |
| RX (Receive): ON = packets are being received | |
| Dimensions | Width: 1.42" [36.0 mm] |
| Depth: 0.53" [13.5 mm] | |
| Height:3.58" [91.0 mm] | |
| Output Wavelengths | -5.5 nm < λc < +7.5 nm |
| Transmiter Power | -6~+0.5dBm |
| Receiver Sensitivity | -14dB |
| Power | +5 V, +3.3 V |
| Power Consumption | 4.0 W |
| Environment | -40 to +85°C operating |
| Shipping Weight | 0.44 lbs. [0.20 kg] |
| Safety Compliance | Wall Mount Power Supply: UL Listed, C-UL Listed (Canada) |
| Regulatory Compliance | FCC Class A, CISPR22/EN55022 Class A, EN55024, EN61000, CE Mark |
| Warranty | 3 years |
Packaging
Shipment
OEM and ODM
OEM/ODM order is available
Guarantee
High quality is our life. We promise all the advertised products are brand new. We absolutely never use old and refurbished materials. Any faulty items can be returned during the warranty time.
We are specialized in supplying network equipments. Our main products are optical transceiver modules and passive CWDM/DWDM multiplexers. The transceiver modules include SFP, GBIC, SFP+, XFP,X2, Xepnak, and CWDM/DWDM transceivers. The transceivers can be compatible with almost all the brands switches.
We supply high quality products with competitive prices. We have professional staff who are always here to provide you technical support and best services.
The most populor modules we often have stock. The items with no stock often have very short delivery time too. If you can't find the items needed on our website you just contact us. We will reply you shortly.
Other Products
1. Q:Do you sell second-hand products?
A:No.All our products are brand new,we never use second-hand components.
2. Q:What payment terms do you accept?
A:T/T,Paypal,Western Union are acceptable.
3. Q:What are the shipping ways can you offer?
A:Our usual shipping ways are DHL,FedEX,TNT,UPS,EMS etc.It will take 3-7days.
4. Q:Do your products come with warranty?
A:Yes,We provide 3 years warranty for all our products from the date of shipment.
5. Q:What devices can your products compatible with?
A:Our products are compatible with Cisco,Huawei, Ciena, H3C, HP, Extreme, Foundry, Brocade, D-link, Alcatel, Riverstone, Enterasys, Netgear, Nortel, Juniper, Ruijie, Zyxel, etc.
6. Q:How to place an order?
A:1>Order details confirmed,please tell us the model and quantity you need.
2>Proforma Invoice confirmed, the order will be arranged upon receipt of your payment.
3>Confirm and ship the goods, then tracking number will be sent to you promptly.
4>We will help to track your goods until you receive them safely.
