Place of Origin:
Guangdong, China
Brand Name:
Hilink
Certification:
CE Rohs
Model Number:
HL-100G QSFP28 AOC Cable
QSFP Cable Series
| Part Number | Description |
| HL-QSFP+40G-Optical cable | |
| HL-QSFP-40G-AOC1M | QSFP+ to QSFP+, Active optical cable 1M |
| HL-QSFP-40G-AOC3M | QSFP+ to QSFP+, Active optical cable 3M |
| HL-QSFP-40G-AOC5M | QSFP+ to QSFP+, Active optical cable 5M |
| HL-QSFP-40G-AOC7M | QSFP+ to QSFP+, Active optical cable 7M |
| HL-QSFP-40G-AOC10M | QSFP+ to QSFP+, Active optical cable 10M |
| HL-QSFP-40G-AOC20M | QSFP+ to QSFP+, Active optical cable 20M |
| HL-QSFP-40G-AOC30M | QSFP+ to QSFP+, Active optical cable 30M |
| HL-QSFP-40G-AOC50M | QSFP+ to QSFP+, Active optical cable 50M |
| HL-QSFP-40G-AOC100M | QSFP+ to QSFP+, Active optical cable 100M |
| HL-QSFP+40G Copper Cable | |
| HL-QSFP-H40G-CU1M | QSFP+ to QSFP+ Passive Copper Cable 1M |
| HL-QSFP-H40G-CU2M | QSFP+ to QSFP+ Passive Copper Cable 2M |
| HL-QSFP-H40G-CU3M | QSFP+ to QSFP+ Passive Copper Cable 3M |
| HL-QSFP-H40G-CU4M | QSFP+ to QSFP+ Passive Copper Cable 4M |
| HL-QSFP-H40G-CU5M | QSFP+ to QSFP+ Passive Copper Cable 5M |
| HL-QSFP-H40G-ACU7M | QSFP+ to QSFP+ Active Copper Cable |
| HL-QSFP-H40G-ACU10M | QSFP+ to QSFP+ Active Copper Cable |
| HL-QSFP-4SFP+ Copper Cable | |
| HL-QSFP-4SFP10G-CU0.5M | QSFP+ to 4SFP+ Passive Copper Cable 0.5M |
| HL-QSFP-4SFP10G-CU1M | QSFP+ to 4SFP+ Passive Copper Cable 1M |
| HL-QSFP-4SFP10G-CU3M | QSFP+ to 4SFP+ Passive Copper Cable 3M |
| HL-QSFP-4SFP10G-CU5M | QSFP+ to 4SFP+ Passive Copper Cable 5M |
| HL-QSFP-4SFP+ Optical cable | |
| HL-QSFP-4SFP10G-AOC1M | QSFP+ to 4SFP+ Active optical cable 1M |
| HL-QSFP-4SFP10G-AOC3M | QSFP+ to 4SFP+ Active optical cable 3M |
| HL-QSFP-4SFP10G-AOC5M | QSFP+ to 4SFP+ Active optical cable 5M |
| HL-QSFP-4SFP10G-AOC7M | QSFP+ to 4SFP+ Active optical cable 7M |
| HL-QSFP-4SFP10G-AOC10M | QSFP+ to 4SFP+ Active optical cable 10M |
Desription:
The Hilink QSFP28 active optic cables are a high performance, low power consumption, long reach interconnect solution supporting 100G Ethernet. It is compliant with the QSFP MSA and IEEE P802.3ba. Hilink QSFP28 AOC is an assembly of 4 full-duplex lanes, where each lane is capable of transmitting data at rates up to 25.78125Gb/s, providing an aggregated rate of 104Gb/s. Hilink QSFP28 AOC is one kind of parallel transceiver which provides increased port density and total system cost savings.
Features:
· Four-channel full-duplex active optical cable
· Transmission data rate up to 25.78Gbit/s per channel
· Reliable VCSEL array technology using multi-mode fiber
· Low power consumption <2.5W
· Operating case temperature: 0℃ to 70℃
· 3.3V power supply voltage
· RoHS 6 compliant
· Hot Pluggable QSFP form factor
Applications:
· Data center
· 100G Ethernet
Product Description
Real Picture
Order details
2~44Channels available. Com port: simplex or duplex. Fiber connector: LC/SC or other
Package: ABS plastic box, LGX metal cassette box, 19inch rack mount. DWDM Solutions and DWDM SFP/XFP.
Shipment & Payment 1. International Express: DHL, Fedex, UPS, EMS, UPS, TNT and etc. 2. Payment: T/T, Western Union, Paypal and so on.
Guarantee:
›& Brand new.
›& OEM/ODM is available. ›& 100% through quality test and aging test. ›& 3 years warranty (From the date of shipment).
