QSFP+ 40G PSM LR4 10KM MPO/MTP QDR/DDR Infiniband Compliant Optical Module
Hilink 40G QSFP+ PSM LR4 is a transceiver module designed for 10km optical communication applications. The design is compliant to 40GBASE-LR4 of the IEEE P802.3ba standard. The module converts 4 inputs channels (ch) of 10Gb/s electrical data to 4 optical signals, and multiplexes them into a single channel for 40Gb/s optical transmission. Reversely, on the receiver side, the module optically
de-multiplexes a 40Gb/s input into 4 channels signals, and converts them to 4 channel output electrical data.
| Item No. | HL-QSFP-PSM-LR4 | Vendor Name | Hilink |
| Form Type | QSFP+ | Max Data Rate | 40Gbps |
| Wavelength | 1310nm | Max Cable Distance | 10KM |
| Interface | MPO/MTP | DOM Support | Yes |
| Cable Type | SMF | Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
Features
4 CWDM channels are 1271, 1291,1311 and 1331 nm
Single +3.3V power supply
QSFP+ MSA compliant
Up to 60km transmission
Operating case temperature: 0~70C
Maximum 3.5W operation power
RoHS compliant
Compliant with IEEE802.3ba
Compliant with QSFP+ MSA: SFF-8436
Specificatioins
| Transmitter | ||||||
|
Wavelength Assignment |
1300 |
1311 |
1320 |
nm |
||
| Side-mode Suppression Ratio | SMSR | 30 | - | - | dB | |
| Average Optical Power per Channel | -5 | - | +1 | dBm | ||
| TDP, each Lane | TDP | 2.3 | dB | |||
| Extinction Ratio | ER | 3.5 | - | - | dB | |
|
Transmitter Eye Mask Definition {X1, X2, X3, Y1, Y2, Y3} |
{0.25, 0.4, 0.45, 0.25, 0.28, 0.4} |
|||||
| Optical Return Loss Tolerance | - | - | 20 | dB | ||
| Average Launch Power OFF Transmitter, each Lane | Poff | -30 | dBm | |||
| Relative Intensity Noise | Rin | -128 | dB/HZ | 1 | ||
| Optical Return Loss Tolerance | - | - | 12 | dB | ||
| Receiver | ||||||
| Damage Threshold | THd | 3.3 | dBm | 1 | ||
| Average Power at Receiver Input, each Lane | R | -12.6 | 0 | dBm | ||
| Receive Electrical 3 dB upper Cut off | 12.3 | GHz | ||||
| Frequency, each Lane | ||||||
| RSSI Accuracy | -2 | 2 | dB | |||
| Receiver Reflectance | Rrx | -26 | dB | |||
| Receiver Power (OMA), each Lane | - | - | 3.5 | dBm | ||
| Receive Electrical 3 dB upper Cutoff Frequency, each Lane | 12.3 | GHz | ||||
| LOS De-Assert | LOSD | -13 | dBm | |||
| LOS Assert | LOSA | -25 | dBm | |||
| LOS Hysteresis | LOSH | 0.5 | dB |
Note:
1. 12dB Reflection
Applications
Rack to rack
Data centers Switches and Routers
Metro networks
Switches and Routers
40G BASE-LR4-PSM Ethernet Links
Compatibility
Hilink optical Transceiver 100% compatibility: Cisco, Huawei, Ciena, H3C, HP, Extreme, Foundry, Brocade, D-link, Alcatel, Mikrotik, Finisar, Netgear, Nortel, Juniper, Ruijie, Zyxel, etc.
