Hilink Compact MPO QSFP+ Transceiver 400G QSFP DD 850nm 100m SR8

Hilink Compact MPO QSFP+ Transceiver 400G QSFP DD 850nm 100m SR8

Compact MPO QSFP+ Transceiver

multimode fiber QSFP+ Transceiver

400G Fiber Optic Module

Place of Origin:

Guangdong, China

Brand Name:

HILINK

Certification:

CE FCC Rohs

Model Number:

QSFP-400G -DD - SR8

Contact Us
Request A Quote
Hilink Compact MPO QSFP+ Transceiver 400G QSFP DD 850nm 100m SR8
Hilink Compact MPO QSFP+ Transceiver 400G QSFP DD 850nm 100m SR8 Hilink Compact MPO QSFP+ Transceiver 400G QSFP DD 850nm 100m SR8 Hilink Compact MPO QSFP+ Transceiver 400G QSFP DD 850nm 100m SR8
Product Details
Product Name:
400G QSFP DD SR8
Application:
400Gbase
Wavelength:
850nm
Distance:
100M
DDM/DOM:
Yes
Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
Negotiable
Packaging Details
Static bag, Plastic bag, Retail box
Delivery Time
2-7 working days
Payment Terms
T/T, Western Union,Paypal
Supply Ability
10pcs/Week
RELATED PRODUCTS
Good price QSFP-LR-40G QSFP LR4 1310NM 10KM MPO QSFP 40G SFP Transceiver Modules online

QSFP-LR-40G QSFP LR4 1310NM 10KM MPO QSFP 40G SFP Transceiver Modules

Get Best Price
Good price 100G QSFP28 ZR4 80KM 1310nm QSFP 80KM LC Transceiver Module DOM online

100G QSFP28 ZR4 80KM 1310nm QSFP 80KM LC Transceiver Module DOM

Get Best Price
Good price 100G Ethernet QSFP28-100G-ZR4 100G QSFP28 ZR4 Optical Transceiver online

100G Ethernet QSFP28-100G-ZR4 100G QSFP28 ZR4 Optical Transceiver

Get Best Price
Good price High Quality QSFP-40G-LR4 20KM Dual LC QSFP+ PSM4 LR4 Optical Transceiver Module online Video

High Quality QSFP-40G-LR4 20KM Dual LC QSFP+ PSM4 LR4 Optical Transceiver Module

Get Best Price
Contact Us
86-755-8317-6243
Contact Now
Product Description

Hilink compact 400G QSFP DD 850nm 100m SR8 MPO Optic Module QSFP Transceiver

PRODUCT FEATURES

  • • Compliant with IEEE Std 802.3bs, IEEE Std 802.3cm
    • Compliant with 400G-SR8 opticalspecifications
    • Compliant with QSFP-DD MSA
    • Compliant with CMIS4.0 Management interface
    specifications
    • 8x53.125Gb/s electrical interface (400GAUI-8)
    • Reach up to 70m on MMF(OM3)
    • Reach up to 100m on MMF(OM4)
    • Single +3.3V power supply
    • Case temperature range: 0 ~ +70℃
    • Maximum power consumption 9W
    • Single MPO16 connector
    • RoHS complaint

APPLICATIONS

  • • 400GBASE-SR8 Ethernet links
    •Data centers

Hilink 400G QSFP-DD SR8 is a 8×50Gbps multi mode fiber, hot pluggable optical transceiver. The module integrates four parallel lanes with baud rate at 26.5625GBd each lane. It can transmit up to 70 m on fiber OM3 fiber or 100 m on OM4 fiber with FEC.







Model Number
400G QSFP-DD-SR8
Data Rate
400G b/s
Wavelength
850nm
Output Power
-6~4dBm
Rx Sensitivity
<-8.0 dBm
Laser
VCSEL
Connector
MPO
Operating Temperature
0°C to 70°C

Hilink Compact MPO QSFP+ Transceiver 400G QSFP DD 850nm 100m SR8 0Hilink Compact MPO QSFP+ Transceiver 400G QSFP DD 850nm 100m SR8 1
